| Model |
PS-SC25 |
| Output |
DC Voltage |
12V / 24v |
| Voltage Accuracy |
±0.5V |
| Rated current |
0 – 1.66A |
| Rated power |
25W |
| Input |
Voltage Range |
90-130VAC 180-250VAC |
| Frequency Range |
47~63HZ |
| Power Factor ( Typ.) |
PF≥0.97/170V PF≥0.95 /220V PF≥0.93/250V |
| Full Load Efficiency(Typ.) |
81% |
| AC Current(Typ.) |
0.14A/180VAC 0.12A/220VAC 0.10A/250VAC |
| Leakage current |
<0.7mA/220VAC |
| Protection |
Short Circuit |
Hiccup mode, recovers automatically after fault condition is removed. |
| Over Current |
< 1.4*Iout |
| Over temperature |
100°C±10°C shut down o/p voltage, re-power on to recover |
| Environment |
Working TEMP. |
-40~+60°C |
| Working Humidity |
20~90%RH,non-condensing |
| Storage TEM.,Humidity |
-40~+80°C,10~95%RH |
| TEMP.coefficient |
±0.03%/°C(0~50°C) |
| Vibration |
10~500Hz,2G 10min./1 cycle,period for 60min.each along X,Y,Z axes. |
| Safety&EMC |
Safety standards |
EN-60950-1. |
| Withstand voltage |
I/P-O/P:3.75KVAC |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:100MΩ/500VDC/25°C/70%RH |
| EMC EMISSION |
Compliance toEN55015,EN61000-3-2 (≥50%load) |
| EMC IMMUNITY |
Compliance to EN61000-4-2,3,4,5,6,8, 11,EN61547,A light industry level |
| Packing |
Weight |
0.2Kg |
| Size |
145*55*20mm (L*W*H) |
| packing |
320x280x215mm /50pcs |
| Notes |
1. All parameters NOT specially mentioned are measured at |
| 220VAC input , rated load and 25°Cof ambient temperature. |
|
| 2.Tolerance:includes set us tolerance,line regulation and load regulation . |
