| AC input voltage range |
90 ~ 305VAC; 127 ~ 431VDC |
| AC inrush current (max.) |
Cold start, 75A at 230VAC |
| DC adjustment range |
±6% rated output voltage |
| Current adjustment range |
50%~100% |
| Over current protection |
95%~108% constant current limiting, auto-recovery |
| Over voltage protection |
110%~140% rated output voltage |
| Setup, rise, hold up time |
2500ms, 80ms, 15ms at full load and 230VAC |
| Withstand voltage |
I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
| Working temperature |
-40~+70ºC (refer to output derating curve) |
| Safety standards |
UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 (except for C-Type) approved; UL1012, UL60950-1, TUV EN60950-1 |
| EMC standards |
EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 |
| Connection Input |
UL rated, SJTW 18AWGx3C (30cm); |
| Connection Output |
A/D/Blank-Type: SJTW 14AWGx2C (30cm) ; B-Type: SJTW 14AWGx2C (30cm)+SJTW 18AWGx2C (30cm); C-Type: Terminal block |
| Dimension (LxWxH) (mm) |
A/B/D/Blank-Type: 244.2x 68x 38.8 C-Type: 251x 68x 38.8 |
